Cbn Insert Cuting Tools

INSERT, CUTTING TOOL: TYPE TURNING, SHAPE ROUND, SIZE DIA 9.53 MM, THICKNESS 3.18 MM, MATERIAL CUBIC BORON NITRIDE, RAKE 0 DEG, FFT: TOLERANCE S 0.13, TOLERANCE IC 0.05,

Types of cbn inserts: soldering compound inserts / solid cbn inserts

Applications of pcbn inserts: Rough and finish machining gray iron, alloy cast iron, hardened steel, brake drums, flywheels, brake discs, mining machinery, electrical equipemnt, machine tools, etc

Model cbn inserts: CCGW, TCGW, CNGA, TNGA, DCGW, RCGX

Specification
The hardness of cubic boron nitride (CBN) is second only to PCD and single crystal diamond. It can still maintain the hardness of cemented carbide at 25 degrees Celsius at a high temperature of 1000 degrees Celsius. The high strength of CBN comes from its intercrystalline bonds. Equipped with a hardness alloy matrix with very good hardness and toughness, the tools made with it can withstand great cutting forces when deep cutting materials with high hardness and high toughness. The intergranular bond also provides acceptable impact strength. This is very necessary when cutting continuous and discontinuous sections.

Applications of CBN inserts

Processing materialsï¼?such as cold work tool steel, hot work tool steel, high speed steel, bearing steel, hardened steel, powder smelting steel, powder smelting metal,martensitic stainless steel ect.

Processing fields: Rough and finish machining gray iron, alloy cast iron, hardened steel, brake drums, flywheels, brake discs, mining machinery, electrical equipemnt, medical, aviation manufacturing, machine tools, etc

[Processing steps]: Inner hole/outer surface turning
[Tool holder type]: Upper pressure type C turning tool
[Outer surface turning tool square size]: 20*20, 25*25, 32*32, 40*40

Due to its excellent properties, carbide rolls are widely used in the steel industry and their hardness is very high. For the machining of cemented carbide rolls, CBN/PCD Inserts can effectively replace the grinding process to improve production efficiency.

Details:
Due to its excellent properties, carbide rolls are widely used in the steel industry and their hardness is very high. For the machining of cemented carbide rolls, CBN/PCD Inserts can effectively replace the grinding process to improve production efficiency.

INSERT TOOLS

IN THE TYPES IN WHICH THE CUTTER PORTION IS AN INDEXABLE PART CLAMPED BY A SCREW, THE CUTTERS ARE CALLED INSERTS (BECAUSE THEY ARE INSERTED INTO THE TOOL BODY). TIPPED TOOLS ALLOW EACH PART OF THE TOOL, THE SHANK AND THE CUTTER(S), TO BE MADE OF THE MATERIAL WITH THE BEST PROPERTIES FOR ITS JOB.

The Solid CBN Inserts are made of cubic boron nitride micro power under the process of super high temperature and high press. Solid of CBN Inserts are used for rough and finish machining. More SuperHard s solid CBN inserts for multiple machining requirements. Whatever your cutting application requires, solid CBN inserts provide the best in geometry, hardness and performance.

Name: Solid CBN inserts
Brief Introduction: solid cbn inserts are used for rough and finish machining of hard steel ,cast iron and hard surface workpiece.
type: RNMN,SNMN,TNGN,CNMN,RCMN,RCMX
application: turning hard steel,cast iron

Details

Usages of PCBN inserts:
1.PCBN bladesare mainly using in processing of hardened steel whose hardness is of HRC50-60. such as: carbon tool steel, bearing steel, die steel, high-speed steel and so on. It also using in processing of gray cast iron, ductile iron, chilled cast iron, and other high temperature alloy and so on.

2.PCD toolsare using in cutting of non-ferrous metals (such as copper, aluminum, magnesium, etc.) and non-metallic materials (such as fiberglass, ceramics, reinforced plastics, etc.)

Advantages:
- Professional Edges design for Milling; Super-precision Edges preparation,
- Faster Material Removal rate,
- Longer Lifetime,
- Lower Composite Cost.

Please don't hesitate to contact me if you have any needs:miya AT moresuperhard.com
Our company also produces a series of diamond and CBN tools,welcome to consult and choose at any time

Name: Solid CBN inserts
Brief Introduction: solid cbn inserts are used for rough and finish machining of hard steel ,cast iron and hard surface workpiece.
type: RNMN,SNMN,TNGN,CNMN,RCMN,RCMX
application: turning hard steel,cast iron

Details
Cubic boron nitride inserts (CBN Inserts) is a high-performance type of cutting tool material from a polycrystalline mass. CBN is a high hardness, high heat resistance crystal synthesized by boron and nitrogen under high temperature and high pressure.
Applications of solid CBN inserts:
Processing workpiece: rough and finish machining of the hard steel ,cast iron and hard surface workpiece.
Processing materials: ferrous materials possessing hardness from approximately 45 HRC as well as gray cast iron, Cr-chilled cast iron and wear alloys on a cobalt, nickel or iron basis.
Usages of PCBN inserts:
1.PCBN bladesare mainly using in processing of hardened steel whose hardness is of HRC50-60. such as: carbon tool steel, bearing steel, die steel, high-speed steel and so on. It also using in processing of gray cast iron, ductile iron, chilled cast iron, and other high temperature alloy and so on.

2.PCD toolsare using in cutting of non-ferrous metals (such as copper, aluminum, magnesium, etc.) and non-metallic materials (such as fiberglass, ceramics, reinforced plastics, etc.)

Please don't hesitate to contact me if you have any needs:miya AT moresuperhard.com
Our company also produces a series of diamond and CBN tools,welcome to consult and choose at any time

Solid CBN-

Product Name : Helicoil insert tool kit
Material : Stainless steel, 304 steel
Type : Automatic, manual operation
Application : For installing or removing or repairing the wire thread inserts
Payment terms : T/T
Packing : Cartoons or wooden cases
